D2-107
Technical Specifications
| Model: | D2-107 |
| Input: | DC22.4V |
| Current: | 350mA±5% |
| Brand: | OSRAM |
| LED Quantity: | 8 Pcs |
| LED Power: | 8W |
| CCT: | 2700K~6000K |
| Warm white/Flux: | 3000K±200K / 690 Lm |
| Cool white/Flux: | 5000K±300K /770 Lm |
| Beam Angle: | 400° |
| Size: | ∮85 x H65mm |
| Cut-out size: | ∮75mm |
| Color: | White |
Specifications
Size
Driver
9A088-Z00 / 9A197-Z00(Dimmable)
Input:AC100~240V / 50~60Hz
Output:DC3~36V / 350mA
Max.1W x 8
Size:86 x 58 x 25mm / 94 x 46 x 28mm
Certification: CE . UL
